| Description: |
| The
Aussie ADB-123 Universal Power Draw Bar has been manufactured
in Australia for over five year. During this period
the factory has produced nearly 10,000 units for worldwide
distribution. Aussie ADB-123s are designed to offer
maximum productivity with excellent craftsmanship at
a very reasonable price. As a true sign of commitment
to you, the customer, and belief in our own manufacturing
capabilities, all our machine tools accessories including
the Aussie ADB-123 & ADB-123SP carry a two-year warranty.
|
|
 |
| |
| ADB-123
Includes: |
|
Regualtor and Gauge; Air Filter, Oil Lubrication; "L"
Bracket With Control and Gauge System Mounted; Complete
ADB-123 Power Draw Bar Assembly; Mounting Screws; Special
Allen Wrench; Fitting; Oil; and Operations and Parts
Manual. The ADB-123 SP Includes All of the aforementioned
plus step step pulley adaptor plate. |
|
| |
|
|
SPECIFICATIONS |
TMD
100 SERIES |
TMD
1000 SERIES |
| MAX.
WORK HEIGHT |
5
3/4” |
5”
|
| DIS.
CHUCK CENTER TO MOUNTING COLUMN |
2 1/2” |
8”
|
| SPINDLE
TRAVEL |
1
1/4” |
1
1/4” |
| SPINDLE
SPEEDS (3) |
9,500
17,000 30,000 RPM |
9,500
17,000 30,000 RPM |
| TABLE
SIZE |
4”
X 4” |
|
| BASE
DIMENSIONS (LxWxH) |
11
3/4” x 7” x 2 3/4” |
11
3/8” x 6 7/8” x 1 1/2” |
| OVERALL
DIMENSIONS (LxWxH) |
11
3/4” x 7” x 15 1/2” |
13
1/8” x 7 1/8” x 18 1/2” |
| NET
WEIGHT |
23
LBS |
25
LBS |
| SHIP
WEIGHT |
34
LBS |
40
LBS |
|
